Titanium Plate
Premium Quality
Titanium Plate
Grade: Gr1、Gr2、Gr3、Gr4、Gr5,Gr9、Gr7、Gr11、Gr12，TB2 Titanium Alloy (Ti-5Mo-5V-8Cr-3Al, GB/T 3620.1)，Ti-15V-3Cr-3Sn-3Al
Manufacturing Method：Hot Rolling;Cold Rolling
Standard: ASTM B265, ASTM F67, AMS 4911, ASME SB265
Processing Method: Polished ;Machined;Acid Pickled
State: Annealed
Surface Treatment:Polished, Machined, Acid
Technical Data
Specifications
| Grade, Manufacturing Method, Supply Condition and Specification of Titanium Plate Products | ||||||
| Grade | Manufacturing Method | Supply Condition | Surface Treatment | Specification | ||
| Thickness / mm | Width / mm | Length / mm | ||||
| Gr1、Gr2、Gr3、Gr4、Gr5,Gr9、Gr7、Gr11、Gr12 | Hot Rolling | Hot-worked (R) Annealed (M) | Polished Machined Acid Pickled | >4.75-60.0 | 400-3000 | 1000-4000 |
| Cold Rolling | Cold-worked (Y) Annealed (M) Solution-treated (ST) | 0.30-5 | 400-1000 | 1000-3000 | ||
| TB2 Titanium Alloy (Ti-5Mo-5V-8Cr-3Al, GB/T 3620.1) | Hot Rolling | Solution-treated (ST) | >4.0-10.0 | 400-3000 | 1000-4000 | |
| Cold Rolling | Solution-treated (ST) | 1.0-4.0 | 400-1000 | 1000-3000 | ||
| Ti-15V-3Cr-3Sn-3Al | Cold Rolling | Solution-treated (ST) | 0.30-4.75 | 400-1000 | 1000-3000 | |
Overview
Product Description
If you are looking for titanium plates with high stability and high quality, we can meet your material selection needs with one-stop service. Our titanium plates adopt pure raw materials and mature craftsmanship, featuring super corrosion resistance and excellent comprehensive mechanical properties. They are widely used in industrial anti-corrosion, medical application, precision manufacturing, high-end equipment and other fields. A full range of grades and thickness specifications are available, and non-standard sizes as well as special process customized processing are supported. Relying on a stable source supply chain, we provide highly customized material solutions for different customers.
Why This Product
Features & Advantages
Compared with ordinary metal plates, our mass-produced titanium plates have fully upgraded comprehensive application advantages. They feature outstanding resistance to acid, alkali and seawater corrosion; light weight and high structural strength effectively realize equipment lightweight upgrading. The material is safe, harmless and highly biocompatible, suitable for medical implantation and sanitary-grade equipment. Meanwhile, it has the advantages of high temperature resistance, non-magnetism, fatigue resistance, easy cutting and welding, and easy forming. With solid overall performance, it can stably cope with various high-strength and high-demand complex working conditions for a long time.
Performance Data
Mechanical Properties
| Room Temperature Mechanical Properties of Titanium Plate | |||||
| Grade | Condition | Plate Thickness / mm | Tensile Strength Rm / MPa | Proof Strength Rp0.2 / MPa | Elongation After Fracture A / %, min. |
| Gr1 | M | 0.3-25.0 | ≥240 | 140~310 | 30 |
| Gr2 | M | 0.3-25.0 | ≥440 | 275~650 | 25 |
| Gr3 | M | 0.3-25.0 | ≥500 | 380~300 | 20 |
| Gr4 | M | 0.3-25.0 | ≥560 | 485-655 | 20 |
| Gr7 | M | 0.8-1.5 1.6-2.0 2.0-5.0 5.0-10.0 | 735-930 | ≥685 | 20 12 12 |
| Gr9 | M | 0.8-10 | ≥240 | 140-310 | 24 |
| Gr7 | M | 0.8-10.0 | ≥400 | 275—450 | 20 |
| Gr11 | M | 0.8-10.0 | ≥240 | 140-310 | 24 |
| Gr12 | ClassA M | 0.8-10.0 | ≥485 | ≥345 | 18 |
| ClassB M | 0.8-10.0 | ≥365 | ≥275 | 25 | |
| Ti-15V-3Cr-3Sn-3Al | ST | 0.8-1.75 >1.75-3.18 | 705-945 | 690-835 | 12 10 |
Where It's Used
Industrial Applications
Our high-quality titanium plates are suitable for high-end manufacturing in multiple industries across the whole industrial chain with a wide range of uses:
- Aerospace: Fuselage structural plates, heat insulation accessories, aviation precision load-bearing components
- Marine and Offshore: Seawater anti-corrosion plates, offshore platform accessories, deep-sea engineering materials
- Chemical Industry: Anti-corrosion reaction equipment, chemical storage tanks, corrosion-resistant pipeline lining plates, valve plates
- Medical Devices: Dental medical plates, human implant base plates, surgical medical precision accessories
- Automobile and Transportation: Lightweight body plates, high-temperature resistant exhaust components, new energy vehicle accessories
- Leisure Manufacturing: High-end outdoor equipment, diving anti-corrosion plates, sports equipment structural parts
- Electronics and Semiconductors: Vacuum equipment panels, conductive base plates, precision electronic anti-corrosion accessories
- Energy and Nuclear Power: Nuclear equipment protective plates, new energy storage structural parts, geothermal engineering components
- Food and Pharmaceutical: Sanitary-grade anti-corrosion panels, pharmaceutical machinery shells, food equipment contact plates
Our Promise
Why Choose Us
(1). Source Factory Strength
- Deeply engaged in the titanium alloy material industry, sufficient spot inventory of full-series titanium materials
- Independent and stable raw material channels to control material purity and finished product quality from the source
- Strong mass production capacity, accepting small and bulk orders and supporting urgent production scheduling
(2). Quality Control and Product Advantages
- Full-process standardized production and processing with layer-by-layer quality inspection in multiple procedures
- Stable and unified performance parameters, high flatness and fine workmanship of plates
- Refuse to mix inferior waste materials to ensure better overall durability and service life
(3). Customization and Delivery Service
- Support personalized requirements such as size cutting, polishing, finish machining and non-standard customization
- Professional foreign trade team provides full-cycle docking with quick quotation and efficient communication
- Strictly arrange production schedule, deliver goods on time and in quantity to ensure customers' project progress
- Factory direct supply with high cost performance, stable and reliable for long-term cooperation
Quality Assurance
Inspection Reports & Certificates
Three-Level Quality Control System, Full Traceability Guarantee. We have established a three-level full-chain quality control system covering incoming raw materials, production process and finished product delivery. For each batch of titanium materials, strict sampling inspection on chemical composition is implemented at the source to prevent unqualified raw materials from entering production lines. During production, quality control points are set in key processes to monitor dimensional accuracy, surface finish and other indicators in real time. Before delivery, finished products pass mechanical performance tests, non-destructive flaw detection and multiple inspections to ensure all performance meets customer requirements.
We can provide complete material certificates and factory inspection reports for all products, ensuring chemical composition, mechanical properties and other indicators comply with ASTM, GB and other domestic and international standards, supplying traceable and trustworthy high-quality titanium materials for global customers.
Source Control
Chemical Composition Analysis
Process Monitoring
Dimensional Accuracy Control
Final Inspection
Traceable Quality Reports
Common Questions
Frequently Asked Questions
Q: What is the minimum order value for products?
A: Please contact us for specific quantity requirements.
Q: Can custom sizes be provided?
A: Yes, we offer customization services based on our manufacturing capacity and standard specifications.
Q: What is the general lead time?
A: Lead time varies by specifications and quantity; standard items are usually shipped within 2‑4 weeks.
Q: Do you provide professional customization?
A: Yes, our design team provides comprehensive professional consultation and application feedback.
