Titanium Rod
Premium Quality
Titanium Rod
Grade：Gr1;Gr2;Gr3;Gr4,Gr7;Gr12;Gr5(Ti-6Al-4VELI);
Surface Treatment：Polished, Turned, Ground, Sandblasted, Pickled
Type：Round Bar
Diameter or Section Thicknessᵇ/mm：>7-230
Length ᵇ/mm：300-6000
Technical Data
Specifications
| Grade, Condition and Specification of Titanium Bars | |||||
| Grade | Supply Conditionᵃ | Surface Treatment | Type | Diameter or Section Thicknessᵇ/mm | Length ᵇ/mm |
| Gr1、Gr2、Gr3、Gr4,Gr7、Gr12 Gr5(Ti-6Al-4V) Gr23(Ti-6Al-4V ELI) | Hot-worked (R) | Polished, Turned, Ground, Sandblasted, Pickled | Round Bar | >7-230 | 300-6000 |
| Cold-worked (Y) | 300-6000 | ||||
| Annealed (M) | 300-3000 | ||||
Overview
Product Description
Our titanium rods deliver stable mechanical properties and long-term durability, fully meeting the operating requirements of various working conditions in modern industry. Produced with standardized processing technology and full-range strict quality control, they feature excellent structural stability and reliable performance under conventional and critical working conditions. Every titanium rod has passed detailed testing and meets international material standards, providing practical and cost-effective material selection solutions for various manufacturing scenarios.
Why This Product
Features & Advantages
• Outstanding corrosion resistance, maintaining stable performance in complex environments such as seawater, acid and alkali.
• Balanced strength and plasticity, ensuring high structural reliability as well as good processing compatibility.
• Combining light weight and high strength, effectively reducing equipment dead weight and improving overall energy efficiency.
• Strong adaptability to high and low temperature environments, with stable mechanical properties in a wide temperature range.
• Excellent cutting and welding performance, supporting customized processing to meet diversified project requirements.
Performance Data
Mechanical Properties
| Mechanical Properties of Titanium Bars | ||||
| Grade | Room Temperature Mechanical Properties, Min. | |||
| Tensile Strength Rm / MPa | Proof Strength Rp0.2/MPa | Elongation After Fracture A/% | Reduction of Area Z/% | |
| Gr1 | 240 | 140 | 24 | 30 |
| Gr2 | 400 | 275 | 20 | 30 |
| Gr3 | 500 | 380 | 18 | 30 |
| Gr4 | 580 | 485 | 15 | 25 |
| Gr6 | 785 | 680 | 10 | 25 |
| Gr7 | 370 | 250 | 20 | 25 |
| Gr12 | 485 | 345 | 18 | 25 |
| Ti-6242S | 886 | 825 | 8 | 20 |
| Gr19 | 825 | 825 | 10 | 25 |
| Gr5 | 895 | 825 | 10 | 25 |
| Gr23 | 880 | 760 | 10 | 15 |
Where It's Used
Industrial Applications
Our titanium rods are widely used in various industries, including:
• Aerospace: Structural parts, fasteners, landing gear components
• Marine & Offshore Engineering: Marine accessories, underwater equipment, seawater treatment parts
• Chemical Industry: Reaction kettles, valves, pipelines and corrosion-resistant supporting parts
• Medical Devices: Implant materials, surgical instruments, precision medical accessories
• Automobile & Transportation: Lightweight components, exhaust systems, high-performance automotive parts
• Sports and Leisure: High-end bicycle frames, golf club heads, diving equipment
• Electronics and Semiconductors: Conductive components, electrode materials, vacuum equipment accessories
• Energy and Electric Power: Nuclear power supporting parts, geothermal equipment, new energy energy storage components
• Food and Pharmaceutical Machinery: Sanitary-grade parts, mixing equipment, material contact components
Our Promise
Why Choose Us
Priority Quality Assurance: Complete quality inspection reports are attached to products, complying with industry standards to ensure stable material quality and on-time delivery.
Strict Quality Control: We adopt rigorous production and testing procedures to deliver products that meet your stringent specification requirements.
Customer-oriented Service: We focus on figuring out your specific needs and provide customized solutions and reliable support for every order.
Professional Technical Support: Our team is equipped with professional titanium material expertise to help you select suitable grades and specifications for your application scenarios.
Quality Assurance
Inspection Reports & Certificates
Three-Level Quality Control System, Full Traceability Guarantee. We have established a three-level full-chain quality control system covering incoming raw materials, production process and finished product delivery. For each batch of titanium materials, strict sampling inspection on chemical composition is implemented at the source to prevent unqualified raw materials from entering production lines. During production, quality control points are set in key processes to monitor dimensional accuracy, surface finish and other indicators in real time. Before delivery, finished products pass mechanical performance tests, non-destructive flaw detection and multiple inspections to ensure all performance meets customer requirements.
We can provide complete material certificates and factory inspection reports for all products, ensuring chemical composition, mechanical properties and other indicators comply with ASTM, GB and other domestic and international standards, supplying traceable and trustworthy high-quality titanium materials for global customers.
Source Control
Chemical Composition Analysis
Process Monitoring
Dimensional Accuracy Control
Final Inspection
Traceable Quality Reports
Common Questions
Frequently Asked Questions
Q: What is its service life in seawater?
A: Service life depends on design and chloride concentration. Grade 2 is far more durable than stainless steel in seawater cooling systems.
Q: Can it be used after pickling?
A: Yes. Grade 2 features strong resistance to common acid cleaning cycles. Proper flushing is recommended to avoid surface residues.
Q: What is the maximum operating temperature?
A: Safe for continuous use at temperatures ranging from 300 to 350°C.
Q: Do you accept trial orders?
A: Yes, we support small‑batch trial orders to help customers verify processing and application suitability.
